Cybernetics
Elements of cybernetic circuits. These objects are part of the standard Dia toolbox.
Example
Download
- Cybernetics.dia example diagram in Dia format
- Cybernetics.svg example diagram in SVG format
Installation
These objects are part of the standard Dia toolbox. To use them simply install Dia: Dia
Advertisement
Object list
|
|
Sensor — left |
|
|
Sensor — right |
|
|
Sensor — bottom |
|
|
Sensor — top |
|
|
Sum, subtracting left input |
|
|
Sum, subtracting right input |
|
|
Sum, subtracting bottom input |
|
|
Sum, subtracting top input |
|
|
Integrator — input left |
|
|
Integrator — input right |
|
|
Integrator — input bottom |
|
|
Integrator — input top |
|
|
Sum |
|
|
Product |
|
|
High pass filter |
|
|
Low pass filter |
|
|
Sine characteristic or input |
|
|
Sigmoid characteristic |
|
|
Saturation characteristic |
|
|
Relay characteristic (sigma) |
|
|
Half wave rectifier or ramp input |
|
|
Full wave rectifier (absolute value) |
|
|
Constant positive shift on the y-axis |
|
|
Constant negative shift on the y-axis |
|
|
Constant factor greater 1 |
|
|
Constant factor between 0 and 1 |
|
|
Constant factor between 0 and -1 |
|
|
Constant factor below -1 |
|
|
Template for custom characteristics |
|
|
Time delay |
